LH650-50

Category Unit Ⅰ Falls Ⅱ Falls Max. hoisting capacity t 25 50 Max. hoisting capacity at jib end (60m) t 9.5 9.26 Max. free standing height m 51.65 Jib length m 30~60 Hoisting speed t 25 12.5 6 50 25 12 m/min 32 64 80 16 32 40 Slewing speed r/min 0~0.61 Luffing time min 2.9 free…

Category Unit Ⅰ Falls Ⅱ Falls Max. hoisting capacity t 12.5 25 Max. hoisting capacity at jib end (60m) t 4.71 4.6 Max. free standing height m 51.65 Jib length m 30~60 Hoisting speed t 12.5 6.25 3 25 12.5 6 m/min 53 106 132 26.5 53 66 Slewing speed r/min 0~0.72 Luffing time min 3 free…

Category Unit Ⅰ Falls Ⅱ Falls Max. hoisting capacity t 25 50 Max. hoisting capacity at jib end (60m) t 5 4.51 Max. free standing height m 51.65 Jib length m 30~60 Hoisting speed t 25 12.5 6 50 25 12 m/min 40 80 100 20 40 50 Slewing speed r/min 0~0.78 Luffing time min 3 free…

Category Unit Ⅰ Falls Ⅱ Falls Max. hoisting capacity t 25 50 Max. hoisting capacity at jib end (66m) t 10.6 10 Max. free standing height m 68.55 Jib length m 31~66 Hoisting speed t 25 12.5 6.25 2.5 50 25 12.5 5 m/min 40 80 120 140 20 40 60 70 Slewing speed r/min 0~0.54 Luffing…

Category Unit Ⅱ Falls Ⅲ Falls Ⅳ Falls Max. hoisting capacity t 6 9 12 Max. hoisting capacity at jib end (55m) t 2.2 2.13 2.06 Max. free standing height m 57.15 Jib length m 30~55 Hoisting speed t 6 3 1.5 9 4.5 2.25 12 6 3 m/min 44 88 110 29 58 73 22 44 55…

Category Unit Ⅰ Falls Ⅱ Falls Max. hoisting capacity t 25 50 Max. hoisting capacity at jib end (60m) t 11.8 11 Max. free standing height m 51.45 Jib length m 45~60 Hoisting speed t 25 12.5 6.25 2.5 50 25 12.5 5 m/min 40 80 120 140 20 40 60 70 Slewing speed r/min 0~0.6 Luffing…
