Rough Terrain Scissor Lift
Work Height 22m A Platform Height-Elevated 20m B Platform Height-Stowed 2.8m C Platform Dimension (Length) 4.56m D Platform Dimension (Width) 2.2m Platform Extension 2.7m Overall Height (Rails Up) 3.91m E Overall Height (Rails Down) 3m F Overall Length 4.95m G Overall Width 2.25m H Wheelbase 3.3m I Ground Clearance 0.4m Platform Capacity 750kg Capacity on…
Work Height 13.8m A Platform Height-Elevated 11.8m B Platform Height-Stowed 1.65m C Platform Dimension (Length) 2.75m D Platform Dimension (Width) 1.52m Platform Extension 1.2m Overall Height (Rails Up) 2.74m E Overall Height (Rails Down) 2.05m F Overall Length 3.5m G Overall Width 1.75m H Wheelbase 1.95m I Ground Clearance 0.24m Platform Capacity 350kg Capacity on…
Work Height 18m A Platform Height-Elevated 16m B Platform Height-Stowed 2.03m C Platform Dimension (Length) 3.98m D Platform Dimension (Width) 1.83m Platform Extension 1.3m Overall Height (Rails Up) 3.16m E Overall Height (Rails Down) 2.47m F Overall Length 4.88m G Overall Width 2.3m H Wheelbase 2.9m I Ground Clearance 0.275m Platform Capacity 680kg Capacity on…
Work Height 15m A Platform Height-Elevated 13m B Platform Height-Stowed 1.83m C Platform Dimension (Length) 3.98m D Platform Dimension (Width) 1.83m Platform Extension 1.3m Overall Height (Rails Up) 2.95m E Overall Height (Rails Down) 2.26m F Overall Length 4.88m/3.98m G Overall Width 2.3m H Wheelbase 2.9m I Ground Clearance 0.275m Platform Capacity 680kg Capacity on…
Work Height 12m A Platform Height-Elevated 10m B Platform Height-Stowed 1.63m C Platform Dimension (Length) 3.98m D Platform Dimension (Width) 1.83m Platform Extension 1.3m Overall Height (Rails Up) 2.74m E Overall Height (Rails Down) 2.05m F Overall Length 4.88m/3.98m G Overall Width 2.3m H Wheelbase 2.9m I Ground Clearance 0.275m Platform Capacity 1150kg Capacity on…
Work Height 14.3m A Platform Height-Elevated 12.3m B Platform Height-Stowed 1.65m C Platform Dimension (Length) 2.9m D Platform Dimension (Width) 1.52m Platform Extension 1.5m Overall Height (Rails Up) 2.75m E Overall Height (Rails Down) 2.05m F Overall Length 3.71/3.14m G Overall Width 1.77m H Wheelbase 2.29m I Ground Clearance 0.24m Platform Capacity 450kg Capacity on…
Work Height 12m A Platform Height-Elevated 10m B Platform Height-Stowed 1.5m C Platform Dimension (Length) 2.9m D Platform Dimension (Width) 1.52m Platform Extension 1.5m Overall Height (Rails Up) 2.6m E Overall Height (Rails Down) 1.9m F Overall Length 3.71/3.14m G Overall Width 1.77m H Wheelbase 2.29m I Ground Clearance 0.24m Platform Capacity 500kg Capacity on…
