Mining Dump Truck
Main Parameters Unit Value Curb weight t 30 Rated payload t 62 Max. speed km/h 41 Max. gradeability % 33 Min. turning radius m 12 Capacity (struck) m³ 30 Capacity (heaped 2:1) m³ 36 Tires / 14.00R25 Engine model / YC6K480-GT30 Engine displacement L 12.16 Emission standard / China…
Main Parameters Unit Value Curb weight t 34 Rated payload t 75 Max. speed km/h 41(MT) / 45.6(AT) Max. gradeability % 33 Min. turning radius m 12 Capacity (struck) m³ 36 Capacity (heaped 2:1) m³ 43 Tires / 16.00R25 Engine model / YC6K580-GT30 Engine displacement L 12.939 Emission…
Main Parameters Unit Value Curb weight t 34.5 Rated payload t 85 Max. speed km/h 40(MT) / 40(AT) Max. gradeability % 32 Min. turning radius m 13 Axle payload t 35+45+45 Steering system / Fully hydraulic Tires / 16.00R25 Engine model / YC6K580-GT30 Emission standard / China Non-road Stage III Engine…
Main Parameters Unit Value Curb weight t 36 Rated payload t 90 Max. speed km/h 40 Max. gradeability % 37 Min. turning radius m 12 Steering system / Fully hydraulic Tires / 16.00R25 Engine model / YCK16775 Emission standard / China Non-road Stage III Engine displacement L 15.939 Rated power…
Main Parameters Unit Value Curb weight t 90 Rated payload t 120 Max. speed km/h 51 Max. gradeability % 24 Min. turning radius m 24.6 Capacity (heaped 2:1) m³ 70 Tires / 30.00R51 Engine model / YC12VTD1450-T300 Engine displacement L 39.2 Emission standard / GB 20891-2014 国 II Rated power…
