| Main Parameters | Unit Value |
|---|---|
| Curb weight | t 36 |
| Rated payload | t 90 |
| Max. speed | km/h 40 |
| Max. gradeability | % 37 |
| Min. turning radius | m 12 |
| Steering system | / Fully hydraulic |
| Tires | / 16.00R25 |
| Engine model | / YCK16775 |
| Emission standard | / China Non-road Stage III |
| Engine displacement | L 15.939 |
| Rated power | kW/rpm 570/1900 |
| Max. torque | N·m/rpm 3200 N · m/1100~1500 r/min |
| Transmission model (AT) | / FC7A260 |
| Capacity | m³ 58(Heaped 2:1) |
Main Parameters Unit Value Curb weight t 30 Rated payload t 62 Max. speed km/h 41 Max. gradeability % 33 Min. turning radius m 12 Capacity (struck) m³ 30 Capacity (heaped 2:1) m³ 36 Tires / 14.00R25 Engine model / YC6K480-GT30 Engine displacement L 12.16 Emission standard / China…
Main Parameters Unit Value Curb weight t 34.5 Rated payload t 85 Max. speed km/h 40(MT) / 40(AT) Max. gradeability % 32 Min. turning radius m 13 Axle payload t 35+45+45 Steering system / Fully hydraulic Tires / 16.00R25 Engine model / YC6K580-GT30 Emission standard / China Non-road Stage III Engine…
Main Parameters Unit Value Curb weight t 90 Rated payload t 120 Max. speed km/h 51 Max. gradeability % 24 Min. turning radius m 24.6 Capacity (heaped 2:1) m³ 70 Tires / 30.00R51 Engine model / YC12VTD1450-T300 Engine displacement L 39.2 Emission standard / GB 20891-2014 国 II Rated power…
Main Parameters Unit Value Curb weight t 34 Rated payload t 75 Max. speed km/h 41(MT) / 45.6(AT) Max. gradeability % 33 Min. turning radius m 12 Capacity (struck) m³ 36 Capacity (heaped 2:1) m³ 43 Tires / 16.00R25 Engine model / YC6K580-GT30 Engine displacement L 12.939 Emission…
