Oscillator

Max. Casing Diamete 3000mm Max. Torque 13500kN·m Max. Force Pull 8445kN Pull Strok 650mm Main Clamp Force 4780kN Swiveling Angle 22° Overall Weight 57000kg

Max. Casing Diamete 2000mm Max. Torque 5570kN·m Max. Force Pull 4520kN·m Pull Strok 600mm Main Clamp Force 3620kN Swiveling Angle 24° Overall Weight 41000kg

Max. Casing Diamete Max. Φ1500 Max. Torque 1985kN·m Max. Force Pull 1880kN Pull Strok 450mm Main Clamp Force 1700kN Swiveling Angle / Overall Weight 13500kg

Oscillator diamete 800~1500mm Upward pressure 2120kN downward pressure 1600kN Oscillator torque 1900kN·m Clamping force 2100kN External dimensions 4280x2600x1750mm Weight of oscillator 15t
