ZR185RC
| Max.drilling diameter | 1300mm |
|---|---|
| Max.drilling depth | 42/54m |
| Max. output torque | 185kN.m |
| Rotary speed range | 5-33Rpm |
| Crowd method | Winch Crowding |
| Crowd force push | 210kN |
| Crowd force pull | 210kN |
| Max. stroke crowd | 11.5m |
| Max. line pull | 160kN |
| Max. speed of line | 80m/min |
| Diameter of wire rope | 26mm |
| Max. line pull | 60kN |
| Diameter of wire rope | 18mm |
| Forward/backward | / |
| Left/right | / |
| Model | QSC8.3-C240-30 |
| Rate power of engine | 179/2200kW |
| Emission standard | Stage Ⅲ |
| Displacement of engine | / |
| Distance of tracks | / |
| Width of track shoe | / |
| Slewing radius | / |
| Operation weight | 55t |
| Max. traction force | / |
| Max. travelling speed | / |
| Overall height | 21000mm |
| Transport with Kelly bar | / |
| Transport height | 3620 (with kelly bar) mm |
