DQ Series
| Model | DQ2604 DQ2754 |
|---|---|
| Parameter | Unit Value/Specification Value/Specification |
| Model | / YCA08 YCA08 |
| Engine type | / 6-cylinder, high-pressure common rail, turbocharged intercooled engine 6-cylinder, high-pressure common rail, turbocharged intercooled engine |
| Fuel tank | L 510 510 |
| Rated motor output | kW 191.5 202.5 |
| Rated voltage | V 600 600 |
| High-voltage battery rated capacity | kW·h 11.55 11.55 |
| Transmission type | / Range infinitely variable transmission with electronic gear shifting Range infinitely variable transmission with electronic gear shifting |
| Speed range | km/h 0-40 0-40 |
| Drive configuration | / Dual-motor coupled drive (with 2-speed AMT mechanical automatic shifting) Dual-motor coupled drive (with 2-speed AMT mechanical automatic shifting) |
| Min. turning radius | m 7.5 7.5 |
| Hydraulic flow rate | L/min 120 120 |
| Remote hydraulic valves (sets) | set 4/5 4/5 |
| Hitch type and category | / 3 3 |
| Hitch lift capacity max. 610 mm behind | kN 70 70 |
| PTO speed options | r/min 540/760/1000 540/760/1000 |
| Air brake | / Dual-circuit air brake Dual-circuit air brake |
| Max. operating weight | KG 12510 12510 |
| L × W × H | mm 5750×2610×3450 (front/rear singles) 5750×2610×3450 (front/rear singles) |
| Wheel base | mm 2950 2950 |
| Wheel track (front/rear) | mm 1890/1900 1890/1900 |
| Min. ground clearance | mm 510 510 |
| Tires (front/rear) | Standard configuration 600 70R38 (front single); 710 70R42 (rear single) 600 70R38 (front single); 710 70R42 (rear single) |
| Min. ground clearance | mm 510 |
| Tires (front/rear) | Standard configuration 600 70R38 (front single); 710 70R42 (rear single) |
