| Product Name |
G630 G825 G830 |
| L × W × H (transport) |
mm 3340×2140×2600 3340×2230×2600 3340×2680×2600 |
| L × W × H (operating) |
mm 3340×2220×2600 3340×2480×2600 3340×2820×2600 |
| Min. ground clearance |
mm 500 |
| Engine |
Brand / Yanmar (Japan) |
| Type/Rated power/Rated speed |
kW{PS}r/ min Water-cooled, 3-cylinder, four-stroke diesel engine; Max. 17.8{24.2}/3600 |
| Number of working rows |
rows 6 8 6 |
| Row spacing |
mm 300 250 300 |
| Hill spacing |
mm 100, 120, 140, 160, 180, 210, 240 |
| Transplanting depth |
mm 10–55 (7 levels) |
| Transverse movement/stroke |
mm/stroke 19.5/14, 15.2/18, 13.7/20, 10.5/26 18.6/12, 15.9/14, 13.9/16, 11.2/20 19.5/14, 15.2/18, 13.7/20, 10.5/26 |
| Pickup depth (vertical) |
mm 10 ～ 18 |
| Leveling system |
/ Electro-mechanical |
| Seedling height |
mm 80 ～ 250 |
| Leaf age |
leaves 2 ～ 4.5 |
| Transmission type |
/ Mechanical + HST |
| Travel speeds |
speeds 3F+3R |
| Field efficiency |
hm 2 /h 0.2 ～ 0.42 0.2 ～ 0.45 0.2 ～ 0.64 |
| Fuel consumption per hectare |
kg/hm 2 ≤ 5.2 |
| Drive type |
/ 4WD |
