CONCRETE MACHINERY
Max. theo. concrete output (L./H.) 100/55m³/h Max. concrete pumping pressure (H./L.) 200/110bar Pump cylinder bore x stroke Φ150×1650mm Concrete cylinder dia × stroke Φ200×1650mm Hydraulic circuit Open Discharge port size Φ180mm Engine type BF6M1013-25T3R/1 Rated engine power/speed 186/2100kW/(r/min) Emission standard Non-road China 3 Chassis type DFL1140B10 Engine type EQH180-52 Maximum net engine power/RPM 129/ 2400kW/(r/min)…
Maximum theorical output 100/50m3/h Maximum theorical pressure on concrete 22/12Mpa Pumping frequency 23/13Min -1 Distribution valve type S Valve Concrete cylinder（diameter×stroke） Φ230mm×1600mm Hopper capacity×feeding height 600L×1500mm Outlet diameter Φ180mm Recommended concrete slump 12-23cm Rated power 186/2100kW/(r/min) Engine moment 1000/1600N.m/(r/min) Maximum displacement 7145cc Pumping system pressure 32Mpa Distribution system pressure 19Mpa Mixing system pressure 14Mpa Capacity…
Maximum theorical output 90/45m3/h Maximum theorical pressure on concrete 24/13Mpa Pumping frequency 30/17Min -1 Distribution valve type S Valve Concrete cylinder（diameter×stroke） Φ230mm×1600mm Hopper capacity×feeding height 600L×1500mm Outlet diameter Φ160mm Recommended concrete slump 12-23cm Rated power 199/2300kW/(r/min) Engine moment 1200/1200-1500N.m/(r/min) Maximum displacement 7470cc Pumping system pressure 35Mpa Distribution system pressure 19Mpa Mixing system pressure 12Mpa Capacity…
Maximum theorical output 100/52m3/h Maximum theorical pressure on concrete 26.5/13.5Mpa Pumping frequency 24/13Min -1 Distribution valve type S Valve Concrete cylinder（diameter×stroke） Φ230mm×1600mm Hopper capacity×feeding height 500L×1430mm Outlet diameter Φ160mm Recommended concrete slump 12-23cm Rated power 247/2200kW/(r/min) Engine moment 1550/1200~1500N.m/(r/min) Maximum displacement 7145cc Pumping system pressure 35Mpa Distribution system pressure 19Mpa Mixing system pressure 14Mpa Capacity…
Maximum theorical output 105/70m3/h Maximum theorical pressure on concrete 28/17Mpa Pumping frequency 31/20Min -1 Distribution valve type S Valve Concrete cylinder（diameter×stroke） Φ200mm×1800mm Hopper capacity×feeding height 600L×1500mm Outlet diameter Φ160mm Recommended concrete slump 12-23cm Rated power 186/2100kW/(r/min) Engine moment 1000/1600N.m/(r/min) Maximum displacement 7145cc Pumping system pressure 35Mpa Distribution system pressure 19Mpa Mixing system pressure 12Mpa Capacity…
Max. Horizontal Reach 29m Freestanding Height 24m Boom Rotation 365° Slewing Braking Normally Closed Weight 19300kg Power Supply 380/50V / Hz Power 15kW System Pressure 35MPa Boom Type 3R Pipeline Diameter DN125mm End Hose 5″×3000 ″×mm 1st Section Length 10.87m 1st Section Articulation 0~85° 2nd Section Length 9.56m 2nd Section Articulation 0~180° 3rd Section Length…
Max. Horizontal Reach 33m Freestanding Height 24m Boom Rotation 365° Slewing Braking Normally Closed Weight 23500kg Power Supply 380/50 V/Hz Power 15kW System Pressure 36MPa Boom Type 4Z Pipeline Diameter DN125mm End Hose 5″×3000 ″×mm 1st Section Length 9.73m 1st Section Articulation 0~90° 2nd Section Length 7.85m 2nd Section Articulation 0~180° 3rd Section Length 7.88m…
Theoretical Rated Output 200m³/h length×width×height 42×18×22m Container quantity of main building 5pcs Container quantity of screw, silo & silo accessory 3.5pcs, Total Power 260kW Discharge Height 4m Main Mixer Nominal volume 4m³ Main Mixer Dry components capacity 6m³
Theoretical Rated Output 180m³/h length×width×height 41×18×21m Container quantity of main building 5pcs Container quantity of screw, silo & silo accessory 3.5pcs Total Power 210kW Discharge Height 4m Main Mixer Nominal volume 3m³ Main Mixer Dry components capacity 4.5m³
Theoretical Rated Output 120m³/h length×width×height 37×17×18m Container quantity of main building 5pcs Container quantity of screw, silo & silo accessory 3.5pcs Total Power 155kW Discharge Height 4m Main Mixer Nominal volume 2m³ Main Mixer Dry components capacity 3m³
