ZS1018RT
| Work Height | 12m |
|---|---|
| A Platform Height-Elevated | 10m |
| B Platform Height-Stowed | 1.5m |
| C Platform Dimension (Length) | 2.9m |
| D Platform Dimension (Width) | 1.52m |
| Platform Extension | 1.5m |
| Overall Height (Rails Up) | 2.6m |
| E Overall Height (Rails Down) | 1.9m |
| F Overall Length | 3.71/3.14m |
| G Overall Width | 1.77m |
| H Wheelbase | 2.29m |
| I Ground Clearance | 0.24m |
| Platform Capacity | 500kg |
| Capacity on Deck Extension | 113kg |
| Drive Height | Full Height |
| Max. Number of Workers | 4/2 |
| Drive Speed (Stowed) | 5km/h |
| Drive Speed (Raised) | 0.4km/h |
| Turning Radius (Inside) | 2m |
| Turining Radius (Outside) | 4.2m |
| Up/Down Time | 45/45s |
| Gradeability | 40%（22°） |
| Max. Working Slope (Lateral/Vertical) | 2°/3° |
| Drive | 4WD |
| Tire | Solid tire |
| Engine | D1105 |
| Engine Power | – |
| Fuel Tank Capacity | – |
| Diesel Tank | – |
| Gross | 4600/4000kg |
| Work Height | 39ft 4in |
| A Platform Height-Elevated | 32ft 10in |
| B Platform Height-Stowed | 4ft 11in |
| C Platform Dimension (Length) | 9ft 6in |
| D Platform Dimension (Width) | 5ft |
| Platform Extension | 4ft 11in |
| Overall Height (Rails Up) | 8ft 6in |
| E Overall Height (Rails Down) | 6ft 3in |
| F Overall Length | 12ft 2in/10ft 4in |
| G Overall Width | 5ft 10in |
| H Wheelbase | 7ft 6in |
| I Ground Clearance | 9.5in |
| Platform Capacity | 1100lb |
| Capacity on Deck Extension | 250lb |
| Drive Speed (Stowed) | 3.1mph |
| Drive Speed (Raised) | 0.25mph |
| Turning Radius (Inside) | 6ft 7in |
| Turining Radius (Outside) | 13ft 9in |
| Gross | 10140/8820lb |
