| Main Parameters | Unit Value |
|---|---|
| Capacity | t/h 165-400 |
| Maximum feeding size | mm 600 |
| Feed port size | mm 1150×760 |
| Unloading Main Conveyor | mm B1000x11600 |
| Feeding Height | mm 4184 |
| Crusher power | kW 132 |
| Installed Power | kW 165 |
| Working Size(lengthxwidthxheight) | mm 15144x3291x4184 |
| Total weight | t 48 |
| Displacement | L 3.6 |
| Capacity | 165-520t/h |
| Engine Power | 300kW |
| Driving Power | 165kW |
| Total Weight | 50/57t |
| Transport size Width x Length x Height | 15.15×3.46×3.878 |
Main Parameters Unit Value Capacity t/h 150-350 Screen Size mm 2000×6500 Maximum Feeding Size mm 100×100 Number of Screen Mesh Layers \ 3 Transport size Width x Length x Height mm 14322x3723x4116 Engine Power kW 103 Total Weight t 35 Power Type \ External Municipal Power Capacity 150-350t/h Engine Power 103kW Driving Power 56kW Total Weight 31t Transport size Width x Length x Height 14.3mx3.72mx4.12m
Main Parameters Unit Value Capacity t/h 115-320 Maximum feeding size mm 210 Main Conveyor Width x Length mm B1000x12500 Discharge Height mm 3300 Crushing Device Power kW 250 Engine Power kW 103 Transport Size Width x Length x Height m 18.05×3.72×3.97 Total Weight t 55 Power Type \ E Capacity 320t/h Engine Power 403/103/441kW Driving Power 321kW Total Weight 52/50/57t Transport size Width x Length x Height 18mx3mx3.55m/18mx3.3mx3.65m/18mx3.3mx3.85m
Main Parameters Unit Value Capacity t/h 180-350 Inlet Size mm 900×1320 Main Conveyor Width x Length mm B1000x13000 Discharge Height mm 3200 Crushing Device Power kW 250 Engine Power kW 103 Transport Size Width x Length x Height m 18×3.55×3.75 Total Weight t 51 Power Type \ E Capacity 180-350t/h Engine Power 118/400kW Driving Power 305kW Total Weight 54/56t Transport size Width x Length x Height 18mx3.55mx3.75m
