PG2004
| Model | PG2004 |
|---|---|
| Parameter | Unit Value/Specification |
| Brand/Model | / YCA07220-S500 |
| Engine type | / 6-cylinder, high-pressure common rail, turbocharged intercooled engine |
| Torque reserve | % 35% |
| Fuel tank | L 375 |
| Transmission type | / Collar shift transmission with partial power shift |
| Gear configuration | / 48F+24R |
| Speed range | km/h 0.41-40 |
| Min. turning radius | m 7.1±0.3 |
| Hydraulic flow rate | L/min 160 |
| Remote hydraulic valves (sets) | set 4 |
| Hitch type and category | / Rear-mounted three-point hitch, category 3 |
| Hitch lift capacity max. 610 mm behind | kN 57.5 |
| PTO speed options | r/min 540/1000 |
| Air brake | / Dual-circuit air brake (EU Standard) |
| Max. operating weight | kg 9150 |
| L × W × H | mm 5342×2600×3250 |
| Wheel base | mm 2858 |
| Wheel track (front/rear) | mm 1980/1950 |
| Min. ground clearance | mm 365 mm under the drawbar |
| Tires (front/rear) | / 540/65R28 (front); 650/65R38 (rear) |
