| Max. Horizontal Reach | 29m |
|---|---|
| Freestanding Height | 24m |
| Boom Rotation | 365° |
| Slewing Braking | Normally Closed |
| Weight | 19300kg |
| Power Supply | 380/50V / Hz |
| Power | 15kW |
| System Pressure | 35MPa |
| Boom Type | 3R |
| Pipeline Diameter | DN125mm |
| End Hose | 5″×3000 ″×mm |
| 1st Section Length | 10.87m |
| 1st Section Articulation | 0~85° |
| 2nd Section Length | 9.56m |
| 2nd Section Articulation | 0~180° |
| 3rd Section Length | 8.53m |
| 3rd Section Articulation | 0~180 |
| Control Mode | Manual / Radio |
| Pipe Cleaning Mode | Water / Dry Cleaning |
Max. Horizontal Reach 33m Freestanding Height 24m Boom Rotation 365° Slewing Braking Normally Closed Weight 20000kg Power Supply 380/50 V / Hz Power 15kW System Pressure 35MPa Boom Type 3R Pipeline Diameter DN125mm End Hose 5″×3000″×mm 1st Section Length 14.87m 1st Section Articulation 0~85° 2nd Section Length 9.56m 2nd Section Articulation 0~180° 3rd Section Length…
Max. Horizontal Reach 33m Freestanding Height 24m Boom Rotation 365° Slewing Braking Normally Closed Weight 23500kg Power Supply 380/50 V/Hz Power 15kW System Pressure 36MPa Boom Type 4Z Pipeline Diameter DN125mm End Hose 5″×3000 ″×mm 1st Section Length 9.73m 1st Section Articulation 0~90° 2nd Section Length 7.85m 2nd Section Articulation 0~180° 3rd Section Length 7.88m…
