ZT14JC

Work Height 44m Platform Height 42m Horizontal Outreach 25m A – Stowed Length 14.95m B – Stowed Width 2.49m C – Stowed Height 2.86m D – Platform Length 2.44m E – Platform Width 0.91m F – Wheelbase 3.81/4.15m Tread 2.46/4.07m G – Ground Clearance 0.4m Platform Capacity (Unrestricted/Restricted) 300/454kg Drive Speed (Stowed) 5km/h Gradeability 45%(24°）…

Work Height 20.6m Platform Height 18.6m Horizontal Outreach 13.3m A – Stowed Length 9.74m(7.6m) B – Stowed Width 2.28m C – Stowed Height 2.57m D – Platform Length 1.83m E – Platform Width 0.76m F – Wheelbase 2.52m Tread 2.28m G – Ground Clearance 0.33m Platform Capacity (Unrestricted/Restricted) 300kg Drive Speed (Stowed) 5.2km/h Gradeability 45%(24°)…

Work Height 22.95m Platform Height 20.95m Horizontal Outreach 15.5m A – Stowed Length 9.4m(6.8m) B – Stowed Width 2.46m C – Stowed Height 2.7m D – Platform Length 2.44m E – Platform Width 0.91m F – Wheelbase 2.52m Tread 2.46m G – Ground Clearance 0.33m Platform Capacity (Unrestricted/Restricted) 300kg/454kg Drive Speed (Stowed) 5.2km/h Gradeability 45%(24°)…

Work Height 40.11m Platform Height 38.1m Horizontal Outreach 25m A – Stowed Length 14.95m B – Stowed Width 2.46m C – Stowed Height 2.86m D – Platform Length 2.44m E – Platform Width 0.91m F – Wheelbase 3.81m/4.15m Tread 2.46/4.07m G – Ground Clearance 0.4m Platform Capacity (Unrestricted/Restricted) 300/454kg Drive Speed (Stowed) 5km/h Gradeability 45%(24°）…

Work Height 16.6m Platform Height 14.6m Horizontal Outreach 12.7m A – Stowed Length 9.6m B – Stowed Width 2.28m C – Stowed Height 2.52m D – Platform Length 2.44m E – Platform Width 0.91m F – Wheelbase 2.36m Tread 2.28m G – Ground Clearance 0.36m Platform Capacity (Unrestricted/Restricted) 300/454kg Drive Speed (Stowed) 5.5km/h Gradeability 45%(24°)…

Work Height 28.70m Platform Height 26.70m Horizontal Outreach 22.1m A – Stowed Length 11.91m B – Stowed Width 2.49m C – Stowed Height 2.82m D – Platform Length 2.44m E – Platform Width 0.91m F – Wheelbase 2.80m Tread 2.49m G – Ground Clearance 0.41m Platform Capacity (Unrestricted/Restricted) 300/454kg Drive Speed (Stowed) 5.5km/h Gradeability 45%(24°）…
