R70-3

Category Unit Ⅱ Falls Ⅳ Falls Max. hoisting capacity t 5 10 Max. hoisting capacity at jib end (60m) t 1.7 1.62 Max. free standing height m 58.5 Jib length m 30~60 Hoisting speed t 1.25 5 2.5 10 m/min 95 38 47.5 19 Slewing speed r/min 0~0.8 Trolley speed m/min 0~100 free standing height 58.5m Radius…

free standing height 40 Radius 60 Capacity 6 tip load 1.3

Category Unit Ⅱ Falls Ⅳ Falls Max. hoisting capacity t 10 20 Max. hoisting capacity at jib end (80m) t 2.5 1.74 Max. free standing height m 64.3 Jib length m 30~80 Hoisting speed t 2.5 10 5 20 m/min 95 38 47.5 19 Slewing speed r/min 0~0.8 Trolley speed m/min 0~88 free standing height 64.3m Radius…

Category Unit Ⅱ Falls Ⅳ Falls Max. hoisting capacity t 2.5 5 Max. hoisting capacity at jib end (50m) t 1.5 1.45 Max. free standing height m 44.2 Jib length m 20~50 Hoisting speed t 0.63 2.5 1.25 5 m/min 100 40 50 20 Slewing speed r/min 0~0.8 Trolley speed m/min 0~100 Travelling speed m/min 0~25…
