R2800-160

Category Unit Ⅱ Falls Ⅳ Falls Max. hoisting capacity t 5 10 Max. hoisting capacity at jib end (60m) t 1.7 1.62 Max. free standing height m 58.5 Jib length m 30~60 Hoisting speed t 1.25 5 2.5 10 m/min 95 38 47.5 19 Slewing speed r/min 0~0.8 Trolley speed m/min 0~100 free standing height 58.5m Radius…

Category Unit Ⅱ Falls Ⅳ Falls Max. hoisting capacity t 8 16 Max. hoisting capacity at jib end (80m) t 2.5 1.74 Max. free standing height m 64.3 Jib length m 30~80 Hoisting speed t 2 8 4 16 m/min 90 36 45 18 Slewing speed r/min 0~0.8 Trolley speed m/min 0~88 free standing height 64.3m Radius 80m…
